Description
CAP Swing Frames
Engineered for Strength, Stability and Sensory Support
The CAP Swing Frame is purpose‑designed to provide a strong, low‑flexibility structure for sensory, therapeutic, and suspension applications. Built with simplicity and performance in mind, the frame offers exceptional rigidity while allowing for fast and efficient on‑site installation.
Ideal for sensory rooms, therapy spaces, schools, and specialist care environments, CAP Swing Frames are engineered to safely support a wide range of sensory attachments and user needs.
Rigid Design with Minimal Flex
The frame’s robust steel construction and braced design ensure minimal movement during use, delivering a stable and confidence‑inspiring experience for users and therapists alike. The simple modular construction allows for quick erection on site, reducing downtime and installation complexity.
Standard Frame Components
Each CAP Swing Frame includes:
- 4 × vertical steel posts
- 4 × structural braces
- 4 × steel base plates with integrated rubber floor protection
- 2 × horizontal beams
- 2 × cross beams
- 9 × M10 load‑rated suspension points
- Safe Working Load (SWL): 1000kg vertical per suspension point
This configuration allows for multiple attachment positions, enabling flexible use across different therapeutic or sensory activities.
Customisable to Your Requirements
Every CAP Swing Frame can be custom manufactured to suit your space and application, including:
- Choice of powder‑coat colours
- Custom frame size (standard sizes are 3m x 3m x 2.2m high and 4m x 3m x 2.2m high)
- Custom quantity and positioning of suspension points
- Optional additional protection to steel posts, where required
A detailed drawing will be provided for client review and sign‑off prior to fabrication, ensuring all dimensions, clearances, and requirements are correct before manufacture begins.
Sensory & Therapeutic Applications
The CAP Swing Frame is suitable for use with a wide variety of sensory and therapeutic attachments, helping support:
- Sensory integration therapy
- Vestibular stimulation
- Calm and regulation activities
- Physical and occupational therapy programs
Attachments are available at an additional cost and can be supplied to suit your specific application.
Transport, Installation & Support
CAP Furniture provides a complete service, including:
- Transport to site
- Professional on‑site assembly
- Support throughout the design, approval, and installation process
This ensures a smooth experience from initial concept through to final installation.
Built for Safety, Precision and Long‑Term Use
Designed with safety, durability, and adaptability at its core, the CAP Swing Frame is a trusted solution for environments where performance and reliability are critical.
Engage CAP Furniture now to discuss your requirements, customise your frame, and begin the design process.
